Specifications
| Acts as | a client/server on CANopen |
| Max Input: | 244 bytes;Max Output: 244 bytes;Max Input+Output: 488 Bytes. |
| CANopen profie | DS-301 V4.02 |
| CIA | Draft Recommendation 303 |
| Supports | node guarding, Heartbeat and NMT functions as CANopen master. |
| Supports. | Heartbeat as CANopen server |
| Easy configuration | with free SST-CP-CFG software tool |
| Operating Temp | -40°F to 158°F (-40 ºC to 70 ºC);Rel. Humidity: 5%-95% RH non-condensing |
| Dimension(W*H*D): | 1.6in*4.9in*4.5in(40mm*125mm*110mm). |
| Mounting | DIN Rail Mounting(35mm). |
In Stock: 0.0
| Stock: | 0.0 Can Dispatch Immediately |
| Factory Lead Time: | 15 Days |
| Price: |
₹ 74,450.00 ₹ 74,450.00₹ 74,450.00 |
