Laser sensor

Model No. XNELE-TM30N Square type
Description Laser sensor
Make Xexagon
Certification CE
Model XNELE-TM30N Square type
Detection mode Thru-beam
Detection distance 30m
Spot diameter ±∅60mm/30m
Indicator light Working indicator light: green; Action indicator: Red
Sensitivity regulation Single coil potentiometer
Output mode NPN open collector
Switch mode L.on (light-in action)/D.on (light-shielding action) can be switched
Response time ≤2ms
light source Laser 650nm (modulation) Class 2
Working voltage 10~30V DC
Current consumption ≤20mA
Environmental illumination Incandescent lamp: 3000 lux or less / Sunlight: 5000 lux or less
Ambient temperature -25℃~+55℃, no freezing
Ambient humidity 35%~85%RH, no condensation
Protection circuit Power reverse polarity protection,surge protection, short circuit protection
Degree of protection IP 65
Material PBT + glass fiber (shell), PMMA (lens)
Way out 2M/3 core cable
Anti-vibration 10~50Hz, 0.5mm amplitude, 2 hours each in X, Y, Z directions
Accessories Screwdriver

In Stock: 0.0

Stock: 0.0 Can Dispatch Immediately
Factory Lead Time: 15 Days

₹ 17,055.00 17055.0 INR ₹ 17,055.00

₹ 17,055.00

    This combination does not exist.

    Add to Cart
